Art. No.

Thread Size

Wire
mm

A
mm

D
mm

H
mm

D1
mm

D2
mm

L3
mm

L1
mm

L2
mm

KG/100

B.L.KG.

TS01-0102-0402

M4

2

5.5

4

8

2.2

4.8

24

125

150

3.3

500

TS01-0102-0502

M5

2

6.5

5

10

2.2

5.5

32

155

215

5

800

TS01-0102-0525

M5

2.5

6.5

5

10

2.7

5.5

32

155

215

5

800

TS01-B0102-0532

M5

3.2

6.5

5

10

3.5

6.35

39

160

220

4.6

800

TS01-0102-0603

M6

3

7.5

6

10

3.3

6.35

39

175

245

8

1250

TS01-0102-0632

M6

3.2

7.5

6

10

3.5

6.35

39

175

245

8

1250

TS01-0102-0604

M6

4

7.5

6

10

4.3

7.5

45

185

255

8.5

1250

TS01-0102-0804

M8

4

11

8

11

4.3

7.5

45

200

275

14

1300

TS01-0102-0805

M8

5

11

8

11

5.3

9

52

205

280

15

2350

TS01-0102-1005

M10

5

12

9

14

5.3

9

52

230

320

25.5

2350

TS01-0102-1006

M10

6

12

9

14

6.4

12.6

64

245

335

29.5

3500

TS01-0102-1206

M12

6

14

12

20

6.4

12.6

64

285

400

49

5100

TS01-0102-1208

M12

8

14

12

20

8.4

16

80

305

420

54.5

5100

TS01-0102-1407

M14

7

15

12

22

7.4

14.2

70

315

435

58

5900

TS01-0102-1608

M16

8

17

16

26

8.4

16

80

360

500

108

8000

TS01-0102-1610

M16

10

17

16

26

10.5

18

90

370

510

112

8000

TS01-0102-2010

M20

10

20

19

30

10.5

18

90

410

560

172

13000

TS01-0102-2012

M20

12

23

19

35

12.6

20

105

430

580

180

13000

TS01-0102-2214

M22

14

30

22

46.5

14.7

25

140

545

715

452

17000

TS01-0102-2416

M24

16

30

25

49

16.9

28

160

625

855

662

20000

TS01-0102-2719

M27

19

34

28

54

20

34.5

200

735

970

752

27000

TS01-0102-3022

M30

22

40

32

62

23.2

40.5

230

825

1080

948

31000

TS01-0102-3626

M36

26

44

36

70

27.5

46

280

930

1200

1366

43000
